Product Description
Operating Speed: 0.05mm-2m/sec|
Operating Frequency:?Mechanical:120ops/min Electrical: 30ops/min|
Insulation Resistance:?>100M? @ 500V DC|
Contact Resistance:??<25m?|
Rated Current/Voltage:?10A/600V AC (EN60947-5-1)|
Electrical Rating:??UL/cUL Listed(E216958) for AC15 A600/ DC13 Q300|
Dielectric Strength:?1000VAC for 1 min between non-continuous terminals|
???????2500VAC for 1 min between each terminal and ground|
Service Life:??? Mechanically 10,000,000, Electrically 500,000|
Operating Temperature:?-25~80?(-13~176°F) without formation of ice|
Humidity
<95%RH|
Weight???? 220-300g|
Degree of protection:? IP67|
