Product Description
impulsion IEC60028-2-27:1987 |
libration?sinusoidal IEC60028-2-26:1995 |
Operating Speed: 0.01mm-1m/sec |
Operating Frequency: Mechanical: 600ops/min Electrical: 60ops/min |
Insulation Resistance: >100m?@500V DC |
Contact Resistance: <25m? max |
Rated Voltage: 250VAC |
Rated Current: 10A |
Dielectric Strength: 1000VACfor 1 min between current carring parts |
2500VAC for 1 min between non-current carrying parts |
Service Life: Mechanically 1×10,000,000 (operations) |
Electrically 5×100,000 (operations) |
Operating Temperature: -40~120? without formation of ice |
Degree of Protection: IP67 |
